Motorola (Symbol) came into existence back in 2006 when electronics industry giant Motorola acquired Symbol Technologies in an effort to increase its presence in the mobile computer marketplace. Symbol Technologies provided Motorola with a broad line of top-quality mobile computing products. The Motorola (Symbol) MC3100 line continues the strong tradition of excellence and dependability.
The Motorola (Symbol) MC3100 Series Mobile Computers have built upon the success of the MC3000 Series. The Motorola (Symbol) 3100 is equipped with a new feature known as Motorola MAX Rugged. Along with its IP54 Category 2 rating, the Motorola (Symbol) MC3100 mobile computers offer maximum protection against drops, dust, and liquids. In addition, you get Advanced encryption, FIPS140-2 certification and utilization of Virtual Private networks (VPNs) with Motorola (Symbol) MC3100 handheld computers, which is also referred to as Motorola MAX Secure.
The Motorola MC3100 may also be referred to as the Symbol MC3100 as Motorola acquired Symbol in 2006; it may also be referred to as the Zebra MC3100 as Zebra then acquired the enterprise mobility business from Motorola in 2014.
Mobility Platform Architecture (MPA) 2.0: Provides the latest best-in-class technology architecture; preserves existing application investments by enabling easy and cost-effective porting of applications from other Motorola mobile computers
Motorola MAX Secure: FIPS 140-2 certification and support for the most advanced encryption and authentication algorithms, as well as Virtual Private Networks (VPNs); enables compliance with the most stringent industry security regulations, including sensitive government applications
Microsoft Windows Mobile 6.X or Windows CE 6.0 operating system: Choose the operating system that best meets your needs: the familiar Windows Mobile environment offers standard business tools and line-of-business applications, a large selection of off-the-shelf applications and an easy application development environment; the Windows CE open platform enables fast and easy development and porting of custom applications
Motorola MAX Sensor: Enterprise-class Interactive Sensor Technology (IST) enables leading edge motion-based applications, including dynamic screen orientation, power management and free-fall event logging
Motorola MAX Data Capture: Capture the data you need today and tomorrow with industry leading advanced laser scanning or imaging technology
• Motorola unmatched laser scanning technology: delivers aggressive performance and accurate capture of all 1Dbar codes – including damaged and poor quality bar codes; patented Liquid Polymer scan element eliminates friction and wear for superior durability and reliability
• Motorola’s advanced imaging technology: aggressive performance on 1D and 2D bar codes: patented illumination system and bright aimer enables fast omni-directional bar code reading, increasing productivity by eliminating the need to align bar code and mobile computer
Backward compatibility with MC3000 accessories: Upgrade to the MC3100 while preserving your existing MC3000 accessory investment
Integrated UHF RFID Tag: Allows enterprises to track and locate MC3100 devices
New rugged audio jack: A secure headset connector eliminates the static associated with wired headset cable movement; ensures voice quality and protects productivity in voice-directed applications
Polycarbonate Insert Mold Decorated (IMD) keypad: Greatly improves keypad durability: eliminates the potential to dislodge an individual key; printing under the polycarbonate layer protects keypad graphics against wear
WLAN: 802.11a/b/g tri-mode radio; comprehensive Voiceover-WLAN support: Enables cost-effective voice and data connectivity in the office and in hot spots; easy integration with virtually any WLAN; CCX v4 certified; supports IPV6; supports 802.11a for voice and data interference mitigation
WPAN: Bluetooth® v2.1 with EDR: Provides a wireless connection to printers and more; provides additional throughput (up to 3 Mbps), improved security and additional profiles for expanded connectivity to more device types
Keypad options: 28-key numeric; 38-key shifted alpha, 48-key alphanumeric: Flexibility to standardize on a single device family, yet meet diverse user and application needs
Comprehensive centralized management: Compatibility with Motorola Mobility Services Platform (MSP) and Motorola Mobility Suite provides superior centralized and remote management of all devices anywhere in the world — from a single console
Physical Characteristics
Dimensions:
• Straight Shooter Imager or Laser: 7.49 in. x 3.25 in. x 1.77 in. (190.4 mm x 82.6 mm x 45.2 mm)
• Rotating Turret Laser: 8.55 in. x 3.25 in. x 1.57 in. (217.12 mm x 82.6 mm x 39.9 mm)
• Gun Configurations: 7.5 in. x 3.2 in. x 6.5 in. (193 mm x 80.8 mm x 166 mm)
Weight (including strap, stylus, and battery):
• Straight Shooter Imager or Laser: 14.95 oz./424 gm (with WLAN)
• Rotating Turret Laser: 13.52 oz./384 gm (with WLAN)
• Gun Configurations: 18.34 oz./520 gm
Display:
• 3.0 in. color (TFT) (320 x 320) display with backlight
• Touch Panel: Chemically strengthened glass, analog resistive touch
• Backlight: LED Backlight
Keypad Options:
• 28-key Numeric, 38-key Shifted Alpha (calculator-style integrated numeric keypad),
• 48-key Alpha-Numeric (calculator-style integrated numeric keypad)
Expansion Slot: User accessible SD/MMC slot; approved for memory expansion only
Notifications: Programmable LEDs; Audio notifications
Performance Characteristics
CPU: Marvell PXA320 624 MHz
Operating System: Microsoft Windows CE 6.0 Pro or Windows Mobile 6.X Classic
Memory:
• 128MB RAM/256MB Flash
• 256MB RAM/512MB Flash
(Batch Only)
• 128MB RAM/512MB Flash
• 256MB RAM/1GB Flash
(WLAN Only)
Power:
• Straight Shooter Imager or Laser: Rechargeable Lithium Ion 4800 mAh @ 3.7Vdc, Smart Battery
• Rotating Turret Laser: Rechargeable Lithium Ion 2740 mAh @ 3.7Vdc Smart Battery
• Gun Configurations: Rechargeable Lithium Ion 4800 mAh @ 3.7Vdc Smart Battery
Application Development: Motorola Enterprise Mobility Developer Kit (EMDK)
User Environment
Drop Specification: Multiple 4 ft./1.2 m drops to concrete across the operating temperature range, Multiple 5 ft./1.5 m drops to concrete at ambient temperature 73° F/23° C; meets and exceeds MIL-STD 810G
Tumble Specification: 500 1.64 ft./0.5 m tumbles (1,000 drops) at room temperature per IEC 68-2-32 tumble specifications
Operating Temp.: -4° F to 122° F/-20° C to 50° C
Storage Temp.: -40° F to 158° F/-40° C to 70° C
Battery Charging Temp.: 32° F to 104° F/0° C to 40° C
Sealing: IP54 category 2; meets applicable EN 60529 sealing specifications
Humidity: 5 – 95% non-condensing
ESD: +/-15kVDC air discharge, +/-8kVDC direct discharge, +/-8kVDC indirect discharge
